8 42071901 Holder Assy.-Regist-R
Holder-Regist-R
EM-30L Class C
Apply a normal amount of Molycoat(EM-30L)
to the hatched areas
9 42087001 Cassette-Assy
Frame-Separation-Assy
Fulcrum of rotation and side Class C
The application of grease protruding over
on the paper carriage surface is not permitted
The standard amount of Molycoat(EM-30L) should be applied to
the shaded portions shown in the figure below before assembly.
