C6100 Series User’s Guide
74
2. Note the positions of the four cartridges: Cyan (1),
Magenta (2), Yellow (3), Black (4).
3. Pull the colored toner release lever on the cartridge to be
replaced towards the front of the printer.
Shown: replacement of the black toner cartridge
WARNING!
If the printer has been powered on, the fuser is HOT.
This area is clearly labelled. Do not touch it.
