C6100 Series User’s Guide
80
2. Note the positions of the four image drums: Cyan (1),
Magenta (2), Yellow (3), Black (4).
3. Lift the image drum, complete with its toner cartridge,
out of the printer. Discard it in accordance with your
local regulations.
WARNING!
If the printer has been powered on, the fuser is
HOT. This area is clearly labelled. Do not touch it.
