Troubleshooting > 45
4. If paper is jammed in the fuser unit, push the lock lever (3) in the direction shown to
release the unit.
Holding the fuser unit (4) by the handle, lift it out of the printer and place it on a flat
surface.
5. Pull up the jam release levers (5) and remove the jammed paper.
WARNING!
Be careful not to touch the fuser unit which may be hot after
printing. If the fuser unit is hot, wait until it cools before
attempting to remove any jammed paper.
4
3
5
To Next Page
