Oki ES7170dn MFP - When Paper Jam Occurs Around the Fuser Unit

When a Paper Jam Occurs
- 10 -
2
1
3
4
5
6
7
13
Close the front cover.
Note
• The front cover cannot be closed if the top cover is not
closed securely.
14
Return the document holder to its original
position.
This completes the procedure.
When Paper Jam Occurs Around the
Fuser Unit
1
Hold the Document holder lever and lift the
Document holder.
2
Insert your finger into the recess on the
right side of the machine and pull the front
cover open lever to open the front cover
forward.
Note
• Open the front cover gently. If you open it rapidly, the
MP Tray may open.
3
Open the top cover.
4
Remove the print cartridge and place it on a
flat surface.
Front cover
Document holder
Document holder
lever
Front cover
Front cover
open lever
Top cover
Print cartridge
