PRINTING FROM WINDOWS
- 19 -
2
1
3
4
5
6
7
- 1/2 13.5'' LG on 13.5'' LG — Select this to print an half
of 13.5 inch LG size booklet. Every 2 pages are printed
on 13.5 inch LG paper to fit on half a sheet.
- 1/2 (Custom) on (Custom) — Select this to print a half
of customized size booklet. Every 2 pages are printed
on customized size paper to fit on half a sheet.
2) Page Order
Select this to print the pages from left to right or right to left.
3) Margin - Center
This sets the gutter in the center of a two-sided page. You
can enter the value between 0 and 0.67 inches (0 and
16.90 mm). The printed images will be reduced according
to the margin setting.
4) Margin - Outer
This sets the gutter on the right side and left side on the
paper. You can enter the value between 0.17 and 1.17
inches (4.20 and 29.60 mm). The printed images will be
reduced according to the margin setting.
5) Margin - Units
Select the unit for the Center Margin and Outer Margin
option. The default unit varies depending on the regional
setting in the Windows.
6) Booklet without Center Margin
Select this to set the center margin of the paper to 0 inch
(mm).
In this case the value set for [Margin - Center] becomes
invalid.
7) Staple Down the Center
Select this to staple the center margin.
8) [Restore Defaults]
Click this to restore the settings displayed in the [Booklet
Details] dialog box to the original factory defaults.
Memo
For detailed instructions on how to print with the
[Booklet] setting, see the following page:
P.41 "Making a booklet"
[Paper Handling] tab
The [Paper Handling] tab allows you to enable Front Cover
printing, Back Cover printing, Inserting Pages, and Interleaving
Pages.
Note
When the size of covers or sheets to be inserted is the same
as that of the copy paper, change the media type or specify
“Paper Source” on the [Basic] tab menu; otherwise all data
will be printed from the insertion tray.
If you select [Store to e-Filing] in the [Print job] box, [Use
Front Cover], [Use Back Cover], [Insert Pages] and
[Interleave Pages] are unselectable.
1) Use Front Cover
This sets front cover printing which allows you to insert or
print a cover on a sheet fed from a different Tray or Multi-
Purpose Tray other than the Paper Source option selected
on the [Basic] tab.
To enable cover printing, select the check box and select
the location from where a cover sheet is to be fed and the
print style to be used.
Memo
For detailed instructions on how to print with the [Use
Front Cover] setting, see the following page:
P.44 "Inserting different types of paper"
Source
Select the location from where a front cover sheet is to be
fed. When [Auto] is selected, the paper is automatically
selected according to the printed document size.
Note
The selectable values in the [Source] box vary
depending on the optional devices installed in this
equipment and their configuration on the [Device
Settings] tab.
Print Style
This selects how you want to print a front cover.
- Do not print on page
— Select this to insert a blank
cover.
- Print one side of the pageSelect this to print the
first page image on the front side of a cover.
- Print both sides of page — Select this to print the first
two page images on both sides of a cover. This is
available only when the 2-Sided Printing option is
enabled on the [Finishing] tab.
Note
If [Print one side of the page] is selected while 2-Sided
Printing is performed, the first page is printed on the
front side of the cover sheet and the back side of the
cover will be blank.
1
2
3
4
