Oki ES7170dn MFP - When Paper Jam Occurs Inside the Machine

When a Paper Jam Occurs
- 7 -
2
1
3
4
5
6
7
10
When loading paper in the multi-purpose
tray, lift the paper set cover and set the
paper with the print side face up.
11
Lower the paper set cover.
This completes the procedure.
When Paper Jam Occurs Inside the
Machine
1
Insert your finger into the recess on the
right side of the machine and pull the front
cover open lever to open the front cover
forward.
Note
• Open the front cover gently. If you open it rapidly, the
multi-purpose tray may open.
2
Pull out the duplex unit by holding the
grips on its both sides.
3
Open the upper cover of the duplex unit
and check for jammed paper in the duplex
unit. If jammed paper remains, pull it out
gently. Then, close the upper cover.
4
Return the duplex unit to its original
position.
Paper set cover
Paper set cover
Front cover
Front cover
open lever
Grip
Grip
Duplex unit
Grip
Grip
Upper cover
Duplex unit
