Oki ES7170dn MFP - Page 75

Maintenance
- 75 -
2
1
3
4
5
6
7
8
Return the print cartridge into the machine.
9
Close the top cover.
Memo
• You can close the top cover smoothly if you close the
front cover halfway. Be careful not to let the front cover
return to its open position.
10
Close the front cover.
Note
• The front cover cannot be closed if the top cover is not
closed securely.
11
Return the document holder to its original
position.
Print cartridge
Top cover
Front Cover
