1. CONFIGURATION
1.2 Structure of MFP
The insides of multi function printers are composed of the following parts.
• Scanner part
• Electronic photography process part
• Paper path
• Duplex part
• 2bin part
• Control part (CU part / PU part )
• Power supply parts (high voltage part/low voltage part)
Figure 1-2 shows the composition of the MFP.
Figure 1-2
Ⓑ
Ⓐ
Ⓐ
Ⓑ
