Oki ES8473 - Page 141

45850101TH Rev.1
3-32
Oki Data CONFIDENTIAL
3. MAINTENANCE MENUS
Upper display Lower display Details Memory
L_DUTY DENS-M V01=***HS01=***H 01-03:First processing for averaging
density
04-06: Second processing for averaging
density
V0X: Density sense value [HEX]
S0X: Density detection value [HEX]
SRAM
V02=***HS02=***H
V03=***HS03=***H
V04=***HS04=***H
V05=***HS05=***H
V06=***HS06=***H
L_DUTY DENS-C V01=***HS01=***H 01-03:First processing for averaging
density
04-06: Second processing for averaging
density
V0X: Density sense value [HEX]
S0X: Density detection value [HEX]
SRAM
V02=***HS02=***H
V03=***HS03=***H
V04=***HS04=***H
V05=***HS05=***H
V06=***HS06=***H
FINAL DENS-K VX=***H SX=***H The same value as V06 and HS06 of
L_DUTY DENS-K
SRAM
FINAL DENS-Y VX=***H SX=***H The same value as V06 and HS06 of
L_DUTY DENS-Y
SRAM
FINAL DENS-M VX=***H SX=***H The same value as V06 and HS06 of
L_DUTY DENS-M
SRAM
FINAL DENS-C VX=***H SX=***H The same value as V06 and HS06 of
L_DUTY DENS-C
SRAM
DB DENS VALUE VK=**** VY=**** Not used SRAM
DB DENS VALUE VM=**** VC=**** Not used SRAM
DELTA-K 01=**** 02=**** 03=**** 01:Light adjustment value [DEC]
02: DB adjustment value (First)[ DEC]
03: DB adjustment value (Second) [DEC]
SRAM
DELTA-K 04=**** 05=**** 06=**** Not used SRAM
DELTA-K 07=**** 08=**** 09=**** Not used SRAM
DELTA-Y 01=**** 02=**** 03=**** 01:Light adjustment value [DEC]
02: DB adjustment value (First)[ DEC]
03: DB adjustment value (Second) [DEC]
SRAM
DELTA-Y 04=**** 05=**** 06=**** Not used SRAM
DELTA-Y 07=**** 08=**** 09=**** Not used SRAM
DELTA-M 01=**** 02=**** 03=**** 01:Light adjustment value [DEC]
02: DB adjustment value (First)[ DEC]
03: DB adjustment value (Second) [DEC]
SRAM
DELTA-M 04=**** 05=**** 06=**** Not used SRAM
DELTA-M 07=**** 08=**** 09=**** Not used SRAM
Upper display Lower display Details Memory
DELTA-C 01=**** 02=**** 03=**** 01:Light adjustment value [DEC]
02: DB adjustment value (First)[ DEC]
03: DB adjustment value (Second) [DEC]
SRAM
DELTA-C 04=**** 05=**** 06=**** Not used SRAM
DELTA-C 07=**** 08=**** 09=**** Not used SRAM
DENS-K 100%=***H OD= **.**** Result of Black detections at multiple
points
SRAM
DENS-K 85%=***H
DENS-K 70%=***H
DENS-K 50%=***H
DENS-K 30%=***H
DENS-K 15%=***H
DENS-Y 100%=***H OD= **.**** Result of Yellow detections at multiple
points
SRAM
DENS-Y 85%=***H
DENS-Y 70%=***H
DENS-Y 50%=***H
DENS-Y 30%=***H
DENS-Y 15%=***H
DENS-M 100%=***H OD= **.**** Result of Magenta detections at multiple
points
SRAM
DENS-M 85%=***H
DENS-M 70%=***H
DENS-M 50%=***H
DENS-M 30%=***H
DENS-M 15%=***H
DENS-C 100%=***H OD= **.**** Result of Cyan detections at multiple
points
SRAM
DENS-C 85%=***H
DENS-C 70%=***H
DENS-C 50%=***H
DENS-C 30%=***H
DENS-C 15%=***H
BEFORE STD=***H DET=***H ADJ=**H Standard value before sensitivity
adjustment, measured value, adjustment
value
SRAM
AFTER STD=***H DET=***H Standard value after sensitivity
adjustment, measured value,
SRAM
• Results will be stored as described in memory filed.
• The contents in SRAM are deleted when the test starts, and values detected at the normal
competition or until the machine stops due to errors are written.
