45850101TH Rev.1
4-14
Oki Data CONFIDENTIAL
4. REPLACEMENT OF PARTS
(7) Slide the Cover-Hinge(L)
⑦
to forward of the machine and remove it.
(8) Slide the Cover-Hinge(R)
⑧
to forward of the machine and remove it.
⑦
⑧
