4. REPLACEMENT OF PARTS
⑥
-2 Plate Assy.-Side-R
Apply a normal amount of
MOLYKOTE (EM-30LP)
Class C
Apply MOLYKOTE (HP300)
(normal amount) to the shafts.
Class C
Bush-FU
Plate-Fuser-Caulking
⑥
-3 Plate Assy.-Side-R
Plate-Fuser-Caulking
Gear-FU-A
Apply a normal amount of MOLY KOTE (EM-30LP)
to the hatched portions.
Class C
