Oki ES8473 - Page 219

45850101TH Rev.1
4-69
Oki Data CONFIDENTIAL
4. REPLACEMENT OF PARTS
⑥
-6 Plate Assy.-Side-R
Apply a small amount of MOLY KOTE (EM-30LP) Class A
Apply a small amount of MOLYKOTE (EM-30LP)
Class A
Apply a small amount of MOLY KOTE (EM-30LP)
Class A
Expanded view
⑥
-7 Plate Assy.-Side-R
Apply a normal amount of MOLY KOTE (EM-30LP) to
the hatched areas.
Class C (8 portions)
