Oki ES8473 - Page 222

45850101TH Rev.1
4-72
Oki Data CONFIDENTIAL
4. REPLACEMENT OF PARTS
⑧
-1 Guide Assy.-Eject_Upper
Pitch-Roller-Backet
Apply a small amount of HANARL
(SF-133) to the hatched areas.
(2 positions)
Class A
⑧
-2 Guide Assy.-Eject_Upper
Apply a small amount of HANARL
(SF-133) to the hatched areas.
(2 positions)
Apply a small amount of HANARL
(SF-133) to the hatched areas.
(2 positions)
Class A
Class A
