4. REPLACEMENT OF PARTS
②
Hinge-Assy.-(L)
Hinge-Assy.-(R)
1) Slider-Hinge(ADF)
Hinge-Assy.-(L)
㻌
Hinge-Assy.-(R)
㻌
Slider-Hinge(ADF)
㻌
EM-D110 Class C
Apply a normal amount of
MOLYKOTE (EM-D110)
to the hatched 8 ribs.
EM-D110 Class C
Apply a normal amount of MOLYKOTE (EM-D110)
to the hatched area.
