Oki MB760dnfax Service Manual

45641001TH Rev.1
11-19 /
Oki Data CONFIDENTIAL
Setting Mode (08)Codes
05/
08
Mode Element
Sub
element
Item Subitem Code
Sub-
code
Details
Default
value
Acceptable
value
RAM Contents
Proce-
dure
08 Setting
Mode
System User
interface
Card reading
device
3500
Device setting 0006
0001
0-
42949
67295
SYS Toenablethee-BridgeIDGate,acardreading device
shouldbesetintheorderof“ABYYZZZZ”.(Enter the
correspondingvaluesto“A”,“B”,“YY”and “ZZZZ”.)
- AB: Special setting
- A: Debugging NIC
0: Not used 1: Used
- B: Interface
0: USB connection 1: Serial connection (KP-2003only)
- YY: Authentication
00: No authentication using card
02:FeliCa(KP-2003 only)
03:Mifare(KP-2005 only)
04:HID(KP-2004 only)
06: RFIdeas
07: USB keyboard emulation authentication device
08: Q-tag
09: Magnetic card I/F
10: NFC (Common setting for Felica/Mifare)
11: NFC (Separate setting for Felica/Mifare)
12: NFC (Dedicated setting for Felica)
13: NFC (Dedicated setting for Mifare)
-ZZZZ:Sub-code(Speciestheusagetypeofcard ID)
0000: No authentication using card
0001: IDm (Felica/NFC-Felica) and (or) UID (Mifare/
NFC-Mifare)
0002: Data (Felica/NFC-Felica/Mifare/NFC-Mifare)
0003: SSFC mode
5
08 Setting
Mode
System User
interface
Card reading
device
3501 Card reader format
information -1
0 0-
42949
67295
SYS ToaccessthedatainthenoncontactICcard,the Key
Information“LLLL”andtheSectorNumber “MMMM”
should be set.
The“LLLL”shouldbesetrst,andthen “MMMM”.
KP-2003:
LLLL:Systemcode(hexadecimal number)
MMMM: Service code (hexadecimal number)
KP-2005:
LLLL:Key information
MMMM: Sector number (hexadecimal number)
5

Oki MB760dnfax Specifications

General

Functionality	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	200, 000 pages
Connectivity	USB 2.0, 10/100/1000Base-TX Ethernet, Host USB
Duplex Printing	Yes
Max Copying Resolution	600 x 600 dpi
Duplex Copying	Yes
Max Scanning Resolution	600 x 600 dpi
Duplex Scanning	Yes
Fax Transmission Speed	33.6 kbps
Scan Resolution	600 x 600 dpi
Weight	32 kg
Printer Type	Laser
Standard Paper Capacity	630 sheets
Operating System Compatibility	Windows, Mac
Printing Type	Monochrome
Paper Size	A4, A5, B5, Letter, Legal
