3.10 HDD Assist Mode (4C)

3.10.1 General description

ThismodeisavailableonlywhenthesecurityHDD(ADI-HDD)ismountedintheequipment.It

enablesyoutocheckthetypeofthemountedHDD,reverttheADI-HDDtothefactorydefaultor

remove keys.

Functions

• Checksthetype(ADIorSATA)ofthemountedHDD.

• DisposesofADI-HDDdatasafelywithoutanyofleakage.

• DeletesimagedatawhenreusingausedADI-HDD.

3.10.2 Operation procedure

(

HDD data

clear

)

[4][C]

[Power]

[STOP]

Operation

Failed

for SATA-HDD

Cancel

[Power] OFF[START]

[Digital Key]

(Select)

TurnthepowerONwhilepressingthe[4]andthe[CLEAR]buttonsimultaneously.Thenthetype

of the mounted HDD is checked and either of the following screens is displayed.

• WhenthesecurityHDDismounted

HDD Assist Mode

Current HDD type: ADI HDD

Select number (1-2) and press START key

1. Revert factory initial status HDD

2. Remove key

System Firmware Version

Update Mode

: xxxx(x.x.x.x)

: 4c Mode

Fig. 3-7
