1.3 Cleaning the Pickup Roller
Note! Clean the pickup roller for tray 2 and tray 3 in the same procedure.
For the MP tray, clean the pickup roller in the same procedure for the feed roller only.
(Pad is not used.)
• Pull out the tray.
• Clean the feeder roller (large) and the feeder roller (small) with a clean cloth wrung
out using clean water
Feed Roller (Large)
Feed Roller (Small)
• Clean the pad portion of the tray with a clean cloth wrung out using clean water
ray 1
Pad
Roller
ray 2, Tray 3
5
