208
Troubleshooting
3
Push the fuser se
parator levers
back as far as possible.
CAUTION!
The area around the fuse
r unit is
extremely ho
t.
T
ouching a
nything other th
an the
indicated lever
s may result in burns.
If you get burned, immediately cool
the skin under cold water
, and then
seek professional medica
l attention.
207
209
