Oki ML280 Elite User Manual

GETTING STARTED > 13
4. Press gently on the ribbon cartridge until you feel it click into
place.
5. Turn the take-up knob (a) in the direction of the moulded arrow
to take up any ribbon slack.
6. Replace the access cover.
I
NSTALLING THE
P
LATEN
K
NOB
If the Platen Knob is not already fitted, align the key way (a) correctly
and push it firmly into place.
CAUTION!
Do not remove the ribbon shield (“X” in graphic above) from the
ribbon!
a
a

Oki ML280 Elite Specifications

General

Color	No
Character pitch	10, 12, 15, 17.1, 20 cpi
Maximum resolution	240 x 216 DPI
Typestyles supported	Double height, Double width, Emphasised, Enhanced, Italics, Overscore, Underline
Maximum number of copies	3 copies
Maximum print speed (draft)	240 cps
Maximum printing width (columns)	160
Mean time between failures (MTBF)	20000 h
Product color	Gray
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	51 dB
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Serial (RS-232), Serial (RS-422)
AC input voltage	220 - 240 V
Voltage tolerance	10 %
AC input frequency	50 - 60 Hz
Power consumption (typical)	60 W

Weight and Dimensions

Depth	275 mm
Width	372 mm
Height	80 mm
