- 14 -
Paper Jams
11
Turn the two belt locking keys
counterclockwise to release the lock.
Note
z
Be careful not to touch the nearby terminals while
turning the belt locking key.
12
Hold the belt unit handles (blue) on the
left and right, and remove the belt unit
at an angle.
Note
z
Do not touch the belt surface or damage the belt.
❶
❷
To Next Page
