- 59 -
Replacing Consumables
❷
Note
z
Be careful not to spill waste toner while removing
the belt unit.
z
Be careful to not pinch your hands or fingers
between the handle and the machine while
removing the belt unit.
z
When removing the belt unit, do not tilt it further
than is needed to remove it.
9
Place the removed belt unit levelly.
Note
z
Place the belt unit on a flat surface, as shown in the
diagram above. Do not stand it on its side.
z
Do not touch the belt surface or damage the belt.
To Next Page
