22 Control elements
Internal Connector: When mounting the small cable drums to the Controller the internal connectors
are establishing electrical contact with the electrical connectors of the Controller. Please make sure that
these connectors are very clean when attaching the cable drums.
Plug Connector: The plug connector needs to be plugged into the Voltage Electrode.
Marker: The cable of each drum is labeled with 25 markers in total. This markers are numbered from 1
to 25 and will help you to place the electrodes at the right position during the measurement.
4.3 Controller
The Controller is responsible to measure the voltage between the measure electrodes. Figure 4.4 shows
all control elements of the Controller.
