HDMIANT
Input
L
R
Input
L
R
RS232C
Control
Port
VGA/Component
HDMIANT
Input
L
R
Input
L
R
RS232C
Control
Port
VGA/Component
Rear of TV
13
Connecting to an Antenna or Video Equipment with Antenna outlet
(For TV and DTV Source)
1. Connect a 75-ohm coaxial cable (or choice of Antenna Cable) from your cable or antenna to the Video
Equipment's IN jack.
2. Connect another 75-ohm coaxial cable from the Video Equipment's OUT jacks to the TV's VHF/UHF jacks
(RF Terminal).
(75-ohm coaxial cable)
(Video Equipment with
Antenna In/Out Socket)
IN
jack
(75-ohm coaxial cable)
(75-ohm coaxial cable)
Disconnect all power sources before making any connection.
OUT
jack
If connecting to Video Equipment with Antenna outlet
Rear of TV
1. Connect a 75-ohm coaxial cable (or choice of Antenna Cable) from your cable or antenna to the TV's
VHF/UHF jack (RF Terminal).
TV Installation and Connection Guide
For 427~432 Models
For 427~432 Models
