MAESTRO SMART

US-ENG- 13

US-ENGLISH

2.5.1 - EVACUATING CONDENSATE WATER DURING AN EMERGENCY (g.33)

Should be a malfunction occur in the condensate drain pan, the unit will stop, and fault code signals will start

ashingorange,greenandredlights(thesecondandthirdLEDsfromtheleft),alteringyouofanalarmstatus.

To temporarily enable the unit to operate until the service technician arrives, you can drain the water out of

the drain pan by following these simple instructions:

a. Remove the bottom cover (9).

b. Place a container to capture the water at least 10 ounces (0.3 l), the remove the cap from the drain valve.

c. After clearing the fault code, plug in the unit.

2.6 - ROUTINE MAINTENANCE

This unit has been designed to reduce routine maintenance operations to a minimum. Clean or replace the

airlteratleastonceamonthorasneeded,shouldtheredLEDfaultcodelightilluminate.Thisprocedure

can be performed by the end user.

• Cleaningthecondensingcoilandcondensatemanagementsystemmustbecarriedoutbyqualied

technicians on a regular basis based on frequency of use.

Depending on how dirty the coil is, the unit’s coil can be cleaned using an air compressor and reservoir.

• Cleanthecoilnswithasoftbrush,butbecarefultodamageorbendthem.Amorethoroughcleaning

can be performed using non-acidic, environmentally friendly detergents and use a damp cloth to gently

clean the surface of the unit.

• Topreventunnecessaryservicecallsfromtheenduser,explainthefunctionalityoftheremotecontrol

and unit operation to the end user.

• Alsoexplainhowtosafelycleanthelterbyrstturnofftheunit.

2.6.1 - CLEANING THE AIR FILTER

Removingorcleaningtheltermustbeperformedwiththeunitturnedoff.

Theprocedureforremovingthelterisasfollows:

a. Manuallyunhookandturnthetopreturnairgrillasindicateding.30

b.Liftthefrontpartofthelter(3)(g.30).

c. Pull slightly to remove the edge from the upper grille.

d.Removethetwoadditionallters,greenpurifyinglter(F1)andblackactivecarbonlter(F2)fromthe

lterrack(g.36).

e. Carefullywashanddrythelters.

f. Replacetheblackactivecarbonlter(F2)onthelterrack(3)andfastenittothespecictabs(g.36).

g.Replacethepurifyingltergreen(F1)ontherstpinthatisonthelterunit,pullitslightlyandfastenit

on the other two pins.

h.Retthelterrackbyinsertingtherearedgeintothegrille(3).

i. Lower the front edge on the unit.

l. Recloseandhookthetopsupplyairgrille(3)(g.37).

To deactivate leD a (if on), after having turned on the unit, press the micro button located on the signal console

(G)(g.B)withapointedobjectforafewseconds.Afterwhich,thedirtyltersignalwillreset.
