Olimpia splendid UNICO EASY S1 User Manual

ENGLISH
EN - 16
3.3 - USE OF THE REMOTE CONTROL
The remote control supplied with the air conditioner is the tool
which allows You to use the appliance in the most comfortable
manner.
It should be handled with care and in particular:
• Keep it dry (do not clean it with water or leave it outdoors in
bad weather).
• Avoid dropping or bumping it.
• Keep it out of direct sunlight.
 • Theremotecontroloperatesbymeansofaninfraredbeam.
• Duringuse,theremustnotbeanyobstaclebetweentheremotecontrolandtheair-conditioner.
• Ifotherappliancesintheroomhaveremotecontrols(TV,stereo,etc...),theremaybeinterference.
• Electronicanduorescentlightsmayalsointerferewithtransmissionsbetweenremotecontrol
and air-conditioner.
• Removethebatteriesincaseofprolongeddisuseoftheremotecontrol.
3.3.a - Insertion of batteries
The batteries are supplied with the machine.
To insert the batteries correctly:
a. Removethebatteriescompartmentcover(gure18).
b.Insertthebatteriesintotherelevantcompartment(gure18).
Checkthepolarityindicatedonthebottomofthecompartment.
c. Closethecompartmentcorrectly(gure19).
3.3.b - Replacement of batteries
The batteries must be replaced when the icon (D12) appears on the display.
Alwaysusenewbatteries.
 Theuseofoldordifferentbatteriescouldgeneratemalfunctioningoftheremote
control.
The remote control uses two dry alkaline 1.5V batteries (AAA.) (Fig.18).
When replacing batteries, replace both and dispose of the dead batteries in the
appropriatecollectioncentresandasrequiredbylaw.
• If the remote control is not used for several weeks or longer, remove the batteries.
Any leaks from the batteries could damage the remote control.
Donotre-chargeordisassemblethebatteries.Donotthrowthebatteriesintothere.
 Theycanburnandexplode.

Olimpia splendid UNICO EASY S1 Specifications

General

Type	Monobloc mobile air conditioner
Timer type	Digital
Noise level	60 dB
Hose diameter	162 mm
On/off switch	Yes
Number of speeds	3
Airflow (low speed)	335 m³/h
Airflow (high speed)	405 m³/h
Refrigerating medium	R410A
Airflow (medium speed)	370 m³/h
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	2.2 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Fan, Heating
Refrigerating medium weight	515 g
Cooling capacity in watts (max)	- W
International Protection (IP) code	IPX0
Cooling capacity in watts (nominal)	2000 W
Heating capacity in watts (nominal)	1800 W
Cooling energy efficiency (EER, W/W)	2.6
Heating energy efficiency (COP, W/W)	2.7
Current	1 A
Connected load	1036 W
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	B
Annual energy consumption (cooling)	- kWh
Hourly energy consumption (cooling)	0.8 kWh
Hourly energy consumption (heating)	0.7 kWh
Control type	Touch
Display type	LED
Product color	White
Housing material	Plastic

Weight and Dimensions

Depth	276 mm
Width	665 mm
Height	693 mm
Weight	35600 g
Package depth	423 mm
Package width	865 mm
Package height	770 mm
Package weight	40900 g
