Olimpia splendid UNICO EASY S1 User Manual

UNICO EASY S1
ENGLISH
EN - 19
3.9 VENTILATION MODE (FAN)
a. Whenthismodeisselected,theappliancedoesn’tperformanyactionbothontemperatureoronair
humidity in the environment, but only maintains it in circulation.
b. This mode can be selected by pressing the key “MODE” once or more (on the remote control or on the
controlpanel)untilwhenthespeciciconisshownonthedisplayofthecontrolpaneland/oroftheremote
control.
-
icon on the control panel - icon on the remote control display
c. In this mode, the fan is always switched on and it is possible to select its desired speed by pressing the
key “FAN” on the remote control or the key
on the control panel.
d. The fan speed is displayed as indicated in paragraphs “3.1” (point SW7) and “3.2” (point D7).
3.10 HEATING MODE (HEAT)
(only for version with heat pump)
a. When this mode is selected, the appliance heats the environment.
b. This mode can be selected by pressing the key “MODE” once or more (on the remote control or on the
controlpanel)untilwhenthespecicicon is shown on the display.
c. In this mode, the fan is always switched on and it is possible to select its desired speed by pressing the
key “FAN” on the remote control or the key
on the control panel.
The fan speed is displayed as indicated in paragraphs “3.1” (point SW7) and “3.2” (point D7).
d. The temperature set-point is included between 17°C and 30°C (from 62 F and 86 F) with 1°C variations
anditcanbesetusingthekeys+/-onthecontrolpanelorwiththekeys▲▼ontheremotecontrol.
e. After a certain time (maximum three minutes) after the activation of the operation mode, the heat pump
activates and the appliance starts delivering warm air.
f. Connect the condensation discharge pipe (paragraph 2.8)
3.11 TIMER MODE
a. This mode allows to program the switching on or the switching off of the appliance.
b. The delay time can be set, activated and cancelled both from the remote control and from the control
panel.
3.11.a Programmed switching on
a. When the appliance is in standby mode, select the operation mode, the desired temperature and ventilation
speed.
- On the control panel: - press and set the switching on delay time with the keys +/-.
- To activate the function, press or wait approximately 5 seconds so that
thesettimeonthedisplaystopsashing(thedisplayreturnstoshowing
the environment temperature).
The icon
lights up.
- On the remote control: - press the key “TIMER ON” to access the function and then press the key
“TIMER ON” once or more until the switching on delay time is set.
  - Directtheremotecontroltowardstheappliance;abeepconrmstheacti-
vation of the function.
- The icon
on the control panel and the indicator “Timer On” on the remote
control display light up.

Olimpia splendid UNICO EASY S1 Specifications

General

Type	Monobloc mobile air conditioner
Timer type	Digital
Noise level	60 dB
Hose diameter	162 mm
On/off switch	Yes
Number of speeds	3
Airflow (low speed)	335 m³/h
Airflow (high speed)	405 m³/h
Refrigerating medium	R410A
Airflow (medium speed)	370 m³/h
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	2.2 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Fan, Heating
Refrigerating medium weight	515 g
Cooling capacity in watts (max)	- W
International Protection (IP) code	IPX0
Cooling capacity in watts (nominal)	2000 W
Heating capacity in watts (nominal)	1800 W
Cooling energy efficiency (EER, W/W)	2.6
Heating energy efficiency (COP, W/W)	2.7
Current	1 A
Connected load	1036 W
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	B
Annual energy consumption (cooling)	- kWh
Hourly energy consumption (cooling)	0.8 kWh
Hourly energy consumption (heating)	0.7 kWh
Control type	Touch
Display type	LED
Product color	White
Housing material	Plastic

Weight and Dimensions

Depth	276 mm
Width	665 mm
Height	693 mm
Weight	35600 g
Package depth	423 mm
Package width	865 mm
Package height	770 mm
Package weight	40900 g
