Olimpia splendid UNICO EASY S1 User Manual

UNICO EASY S1
ENGLISH
EN - 21
d. Press the key “SLEEP” on the remote control to stop the function; the icon on the control panel and on
the remote control display turn off.
3.12.c FOLLOW ME function
• This function can be activated only from the remote control.
• This function is not available while the Dehumidication (DRY) and Fan Only (FAN) modes are
active.
In this function, the remote control serves as a thermostat.
a. When the appliance is running, press the key “FOLLOW ME” on the remote control.
b. Move with the remote control in an area of the room different from where the appliance is positioned
(maximum distance is 7÷8 metres) directing it towards the appliance itself and making sure there are no
obstacles between them.
c. Set the desired temperature on the remote control; the appliance works until it takes the temperature of
the area where the remote control is positioned to the value set on the remote control itself.
d.Theremotecontrolsendsasignaltotheapplianceand,ifitdoesn’treceivearesponsewithinamaximum
time of 7 minutes, the function deactivates.
e. Press the key “FOLLOW ME” on the remote control or switch the appliance off to stop the function.
3.12.d Setting the unit of measurement of temperature
It is possible to choose the set and environment temperature unit of measurement choosing between °C
(Celsius) or F (Fahrenheit).
Work as follows:
- On the control panel, press the keys + and - at the same time for approximately three seconds.
The desired unit of measurement appears on the display of the control panel.
- On the remote control, keep the central key TEMP pressed for approximately three seconds.
The desired unit of measurement appears on the display of the remote control.
The unit of measurement change must be performed both on the control panel and on the remote
control.
3.12.e Directing the air ow
• This function can be activated only from the remote control.
a. Whentheappliancestarts,theapopenscompletely.
b. Press the key “SWING”ontheremotecontrolandtheapstartsoscillatingautomatically.
c. Press the key “SWING”tostoptheapinacertainposition.
Press it again to restart oscillation.
3.12.f Short Cut function
• This function can be activated only from the remote control.
a. When the appliance is running in any of its modes, press the key “SHORT CUT” on the remote control
andtheapplianceautomaticallyconguresitselfto“AUTO” with a set temperature of 26°C (80 F).

Olimpia splendid UNICO EASY S1 Specifications

General

Type	Monobloc mobile air conditioner
Timer type	Digital
Noise level	60 dB
Hose diameter	162 mm
On/off switch	Yes
Number of speeds	3
Airflow (low speed)	335 m³/h
Airflow (high speed)	405 m³/h
Refrigerating medium	R410A
Airflow (medium speed)	370 m³/h
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	2.2 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Fan, Heating
Refrigerating medium weight	515 g
Cooling capacity in watts (max)	- W
International Protection (IP) code	IPX0
Cooling capacity in watts (nominal)	2000 W
Heating capacity in watts (nominal)	1800 W
Cooling energy efficiency (EER, W/W)	2.6
Heating energy efficiency (COP, W/W)	2.7
Current	1 A
Connected load	1036 W
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	B
Annual energy consumption (cooling)	- kWh
Hourly energy consumption (cooling)	0.8 kWh
Hourly energy consumption (heating)	0.7 kWh
Control type	Touch
Display type	LED
Product color	White
Housing material	Plastic

Weight and Dimensions

Depth	276 mm
Width	665 mm
Height	693 mm
Weight	35600 g
Package depth	423 mm
Package width	865 mm
Package height	770 mm
Package weight	40900 g
