2
Preparation before Use
2-45
NOTE: In Windows XP or Windows Vista, follow the procedure below to set the port.
1 In Windows XP, from [Start] button on the Windows, select [Control Panel], and then [Windows Firewall].
In Windows Vista, from [Start] button on the Windows, select [Control Panel], [Security], and then [Turn Windows
Firewall on or off].
If the User Account Control dialog box appears, click the [Continue] button.
2 Click the Exceptions tab and then the Add port... button.
3 Specify Add a Port settings.
Enter any name in "Name" (example: Scan to SMB). This will be the name of the new port. Enter "445" in "Port
Number". Select TCP for "Protocol".
4 Click the OK button to close the Folder Options screen.
In Windows 8, follow the procedure below to set the port.
1 In charms on Desktop, click [Settings], [Control Panel], [System and Security], and then [Windows Firewall].
If the User Account Control dialog box appears, click the [Continue] button.
2 Configure the settings, refer to Configuring Windows Firewall (for Windows 7) on page 2-42.
To Next Page
