29Service Guide
Replacing Parts
3 Make sure that the Fiery ES is connected to the printer, and both service switches are in OFF position (see Figure 12 on
page 28).
4 Power on the Fiery ES, and then the printer (see page 12).
Wait until the Fiery ES reaches Idle.
5 At the main menu on the printer control panel, select Motherboard replacement.
The printer control panel displays “Reading dongle...”, then displays the number of licenses left to apply to the transfer.
6 At Apply license? screen, select Yes to confirm transfer.
The printer control panel displays “Applying” to indicate the transfer of options and the backup BIOS information from
the hard disk drive to the BIOS chip on the FRU motherboard.
A status bar appears to show the progress. Wait for a few minutes until the process is complete.
7 When New license applied message displayed, make sure to remove the dongle from the USB connector, and then
select Reboot Server.
8 Allow the Fiery ES to reboot and become Idle.
Restoring Fiery ES functionality after service
Complete your inspection and service by reinstalling and verifying the Fiery ES.
To reinstall and verify the Fiery ES
1 Reseat all cables, connectors, and other parts loosened or removed during service.
When routing cables in the Fiery ES make sure that:
• Covers are securely installed after routing cables.
• Cables are not looped around circuit boards or components (such as capacitors and resistors).
• Cable routing does not interfere with the operation of internal components.
• Cables do not lie on or against any internal heating element.
• Cables do not interfere with removing or replacing components.
• Cables do not interfere with opening or closing Fiery ES panels.
• Cables are not tangled.
• Cable slack is secured with a tie-wrap.
Important: Improper connection of the internal power cables can damage the Fiery ES. See “Checking Fiery ES
internal connections” on page 19.
