The installation must obey the rules below:
1. The cables must have a distance more than 40 cm away from any mains cable (230 VAC)
2. The cables must have a distance more than 5 meters away from motor/power stations.
3.5. Useful information for panel installation
Please follow the steps below for every installation of a GR-6500:
) First, you must set the address of each device. To change it, set the dip-switch accordingly,
which is located on the upper side of each luminaire module.
) It is essential to draw a schematic of the complete installation. The schematic must include
cable length, cable cross-section, and the location of each device. This will be useful to locate
where a fault or a shortcut occurs.
) If the installation is in an industrial place or the loop passes near a motor, or ballasts or other
devices which does not comply to CE in radiation activity, then a shielded cable is needed.
) Always observe polarity throughout.
) Non color coded conductors should be identified (e.g. with labels).
) Before we connect the cable we must check for three common faults
a) Shortcuts (with the help of a multimeter),
b) Reverse polarity of the cable loop
c) Open or short circuit of loop cable (with the help of a multimeter).
3.6. Network connection
The GR-6500 panel can be connected to a Local Area Network via Ethernet and can be accessed
remotely via a PC and a common web browser. The Ethernet network connectivity, is provided by the
GR-8530 Ethernet card (10BASE-T controller) (optional accessory - contact your sales
representative). Connect the panel to network via the RJ45 connector on bottom right corner (interior).
