6. Technical Characteristics – Specifications
Description
GR-6500
1 loop 16 zone adressable luminaire panel
Power Supply
220-240VAC/50-60HZ
Consumption
25W (0.150A AC)
Battery type
Sealed lead acid (Pb) battery 12V / 7Ah Max
Charger
Stabilized power supply 13,8V / 400mA
Loop circuit
The maximum number of addressable modules connected to the
panel is 250.
24V output
General outputs with a 24VDC 300mA rating.
Output Relay
3 relay outputs with volt-free contacts (NC,C,NO).
Maximum load
The maximum load connected to the panel must not exceed 0.6Α.
Degrees of cover protection
IP 30
Humidity
Up to 95% relative humidity
Constructional material
ABS/PC, PC
Dimensions
322 x 241 x 97 mm
Weight
1400 gr
Produced in accordance with
EN 50172, EN50130-4, EN 61000-6-3
Guarantee
2 years
