16
If the control box (BX3M-CB) is combined, set the main switch of
the control box to
(ON). When the power is ON, the beep sound is
heard once.
If the control box for coded function (U-CBS) is combined, set the main
switch of the control box for coded function to
(ON).
If following units are combined, set the main switch of respective unit
to
(ON).
Combinable units Unit to set to ON
Mercury lamp housing
Main switch of the power supply for
mercury burner (U-RFL-T)
Light source
Main switch of the light source
(U-HGLGPS)
Halogen lamp housing
Main switch of the halogen lamp power
supply unit (TH4)
LED lamp housing
Main switch of the Power supply for
LED (BX3M-PSLED)
For details, refer to the instruction manual provided
with the respective unit.
1
2
3
3-2 Turning ON the main switch
The reflected LED light illuminator for BF (BX3M-KMA-S) is available
only for the brightfield observation. The other observation methods
cannot be selected.
Select the observation method with the observation method selector
knob.
Display Function
BF The brightfield observation is selected.
DF The darkfield observation is selected.
DIC/PO
The differential interference contrast
observation or the polarization
observation is selected.
1
1
When BX3M-RLAS-S is combined
2
When BX3M-KMA-S is combined
3-3 Selecting the observation method
1
