17
BXFM
Select the observation method using the brightfield/darkfield selector
knob.
Display Function
BF The brightfield observation is selected.
DF The darkfield observation is selected.
· Slide the brightfield/darkfield selector knob to the stopper
position completely.
· The dummy slider
a
is attached to the nosepiece as a
factory default. Be sure to keep this dummy slider inserted
to prevent flares before use.
1
3
When BX3M-RLA-S is combined
Turn the turret to select the observation method.
You can check which No. selects which observation method by
the inscription pocket
a
. Note that the indicator sheet should be
inserted properly in the inscription pocket when attaching the mirror
unit.
Indicator sheet Function
BF Brightfield observation
BFL
Brightfield observation
(Use when the mercury lamp housing is
combined.)
DF Darkfield observation
DIC/PO
Differential interference contrast observation
/ Polarization observation
FL(WBS) Fluorescence observation with B excitation
FL(WGS) Fluorescence observation with G excitation
FL(WUS) Fluorescence observation with U excitation
1
4
When BX3M-URAS-S is combined
1
a
a
