Olympus CX21 Instructions

4
CX21
STANDARD COMPONENT UNITS
}After opening the package, make sure that the correct component units for the selected set are present.
· The differences between the CX21FS1 and CX21FS2 lie in the number of objectives and presence of immersion oil.
# The objectives have been screwed in tightly to prevent them from being loosened during transportation. To
remove an objective, turn it counterclockwise while holding it with a rubber sheet, etc., so that your fingers don’t slip.
Eyepieces
(Fixed at 10X)
Stage
Condenser
Binocular observation
tube
Revolving nosepiece
Microscope frame
Objectives
· 4X, 10X, 40X, 100X
(CX21FS1)
· 4X, 10X, 40X
(CX21FS2)
6V20WHAL halogen bulb
Immersion oil
· Provided with a set including
the 100X objective.
Daylight (blue) filter
Optional Accessories
· Cord Hanger
CH3-CH
· Filter Holder
CH2-FH
· Reflection Mirror
CH20-MM
· Eyepieces
WHC15X
WHC15X-H
· Darkfield Ring
CH2-DS

Olympus CX21 Specifications

General

Type	Biological Microscope
Power Supply	AC 100-240V, 50/60Hz
Eyepiece	Widefield 10x
Objective Lenses	4x, 10x, 40x, 100x
Nosepiece	Quadruple
Stage	Mechanical stage
Focus	Coaxial coarse and fine focusing
Illumination	LED
Condenser	Abbe condenser NA 1.25
Optical System	UIS2 optical system
Eyepiece Tube	Binocular
