CX21 MAINTENANCE MANUAL REPAIR PROCEDURE
- 14 -
2. Mechanical Adjustment
2-1 Preparation for the tension adjustment of X/Y-wire
If a specimen image is moved when the stage is brought into the desired position of
specimen, it is necessary to adjust the wire tension of stage.
1)
2) 3)
OLYMPUS
CX21
75
70
60
50
100
110
120
130
140
150
17
160
0
10
20
30
(a)
Take off the mechanical stage (A) from the plane stage (B)
by removing the two screws (*1).
(A)
(B)
*1
arrow view (a): bottom
*1
(B)
(A)
*1: Fixing screws of mechanical stage
Screw: AB3X10SA (*1), 2 pcs.
Remove the specimen holder (C) from the
inner guide (D).
Screw: 3PSK2X4SA (*2), 3pcs.
(D)
*2
(C)
X-wire
* For the tension adjustment of Y-wire,* For the tension adjustment of X-wire,
refer to next page. refer to next page.
Remove the Y-cover (E).
Screw: CUTB3X8SA (*3), 3pcs.
*3
<indicated by arrows>
(E)
Y-wire
