Olympus DS 30 - Identification of Parts

11
1
Identification of Parts
Identification of Parts
e
=
-
)
q
w
^
%
$
&
*
(
1
3
4
5
#
!
0
@
6
7
8
2
9
# FOLDER/ button
$ VOLUME (
+) button
% 9(Fast Forward) button
^ VOLUME (
- ) button
& 0(Rewind) button
* OK/MENU button
( ERASE button
) EAR (Earphone) jack
- MIC SENSE(Microphone
Sensitivity) switch
= PC (USB) terminal
q Battery cover
w Power jack
e Built-in speaker
1 Exclusive stereo microphone
(ME53S)
2 MIC (Microphone) / REMOTE jack
3 Built-in monaural microphone
4 REC (Record) button
5 STOP button
6 PLAY button
7 DISPLAY/Podcast button
8 POWER/HOLD switch
9 Strap hole
0 Record/Play indicator light (LED)
! Display (LCD panel)
@ LIST/INDEX button
