Olympus E-P5 User Manual

10 EN
Preparing the camera and fl ow of operations
1
Charging and inserting the battery
1
Charging the battery.
Charging indicator
BCN-1
Charging in
progress
Lights orange
Charging
complete
Off
Charging error
Blinks orange
(Charging time: Up to
approximately 4 hours)
1
2
3
AC wall outlet
AC cable
Lithium ion charger
Lithium ion battery
Direction indicating mark ()
Charging indicator
# Cautions
• Unplug the charger when
charging is complete.
2
Loading the battery.
3
2
1
Battery/card
compartment lock
Battery/card
compartment cover
Direction
indicating
mark
Removing the battery
Turn off the camera before opening or closing the
battery/card compartment cover. To remove the
battery, fi rst push the battery lock knob in the direction
of the arrow and then remove.
# Cautions
• Contact an authorized distributor or service center if you are unable to remove the
battery. Do not use force.
$ Notes
• It is recommended to set aside a backup battery for prolonged shooting in case the
battery in use drains.
• Also read “Battery and charger” (P. 112).

Olympus E-P5 Specifications

General

Sensor Type	Live MOS
Sensor Size	17.3 x 13.0 mm (Four Thirds)
Continuous Shooting Speed	9 fps
LCD Screen Size	3.0 inches
LCD Screen Resolution	1, 037, 000 dots
LCD Type	Tilting touchscreen
Built-in Wi-Fi	Yes
Dimensions	122 x 69 x 37 mm
Image Processor	TruePic VI
Shutter Speed	60-1/8000 sec
Built-in Flash	Yes
Battery Life	Approx. 330 shots
ISO Sensitivity	ISO 200-25600
Image Stabilization	Sensor-shift
Autofocus System	Contrast Detection AF
Weight	420 g
Viewfinder	Optional external
Effective Pixels	16.1 Megapixels
Battery Type	Lithium-Ion BLS-5
