Olympus IX71 - Page 13

9
IX71/IX51
Other Modules
Monocular Tube
U-MO
10X eyepiece
(Fixed)
Trinocular Observation Tube H
U-TR30H-2
Straight photo tube mount (Page 44)
Light path selector knob
(Page 21)
Plain Stage
IX2-KSP
Manipulator mounting
screw holes
CK40-MVR/CK2-SS
mounting screw holes
Plain Stage
IX2-SP
IX-MVR/CK2-SS
mounting screw holes
(On both sides)
Manipulator mounting
screw holes
M6 screws (x 6)
Cross Stage
IX-SVL2
Y-axis knob
}Can be mounted on the IX2-KSP.
Y-axis knob
X-axis knob
}Can be mounted on the IX2-SP.
Y-axis knob
X-axis knob
Intermediate Tube
IX-ATU
Mechanical Stage
CK40-MVR
Mechanical Stage
IX-MVR
M6 screws (x 6)
(On both sides)
X-axis knob
