11
IX71/IX51
Power Supply Unit
TH4
}The applicable halogen bulb is the 12V100WHAL-L.
For details, refer to the separate instruction manual.
Light intensity control knob
POWER LED
REMOTE LED
Hand Switch TH4-HS
}The IX71 does not need this module because its
functions are incorporated in the microscope frame.
Light intensity control
knob
Lamp ON-OFF
switch
Power Supply Unit
TL4
}The applicable halogen bulb is the 6V30WHAL.
Light intensity control knob
Lamp socket
connector
Main switch
: ON. : OFF.
Main switch
: ON. : OFF.
