2.5 S-cord (MAJ-813)
1. Plug on the unit side
This plug connects to the electrosurgical unit to the endoscope via S-cord.
2. Plug on the endoscope side
This plug connects the endoscope to the electrosurgical unit via the S-cord.
2.6 P cord (MAJ-814)
1. Plug on the unit side
This plug connects the patient plate to the electrosurgical unit via the P cord.
2. Clamp
This clamp connects the patient plate to the electrosurgical unit via the
P cord.
3. Lever-locking arm
This arm locks the clamp securely in the connector of the patient plate.
2. Plug on the
endoscope side
1. Plug on the unit side
2. Clamp
1. Plug on the
unit side
3. Lever-locking
arm
