Chapter 5 Operation
57
ELECTROSURGICAL UNIT PSD-30
When using the P-plate (MB-574)
When disconnecting each side of P cord (MAJ-3) and
P adapter, always hold the plug on the unit side or patient
plate clamp. Pulling the cable may result in the breaking of
the wires.
1. Turn the electrosurgical unit OFF.
2. Remove the patient plate from the patient.
3. Rotate the Clamping Ring of the P cord counterclockwise and disconnect.
4. Disconnect the plug on the unit side of the P cord from the P cord connector
of the P adapter. Disconnect the plug on the unit side of P adapter from the
Patient connector on the front panel.
5. Disconnect the A-cord’s plug on the accessory side from the accessory for
the endoscope. Disconnect the A-cord’s plug on the unit side from the
Active connector on the front panel.
6. Following endoscopic treatment, disconnect the S-cord’s plug on the
endoscope side from the endoscope’s S-cord connector mount. Pull the ring
on the S-cord’s plug outward and disconnect the S-cord from the S-cord
connector on the front panel (for an endoscope equipped with the S-cord
connector mount).
7. When the foot switch is no longer needed, rotate the fastener ring on the
Foot switch plug counterclockwise and disconnect the plug from the Foot
switch connector on the rear panel.
8. If the electrosurgical unit is not to be used for a long period, disconnect the
power cord plug from the wall mains outlet.
