9
Item Specifications
Model SZ2-STB3
Microscope attaching method
Insertion (attaching hole diameter 76 mm). Attaching using a clamping knob.
Focus adjustment Up/down movement with rack & pinion and dovetail guide.
Focus adjustment stroke 43 mm.
Focus adjustment knob tension adjustable.
Illuminator (LSGA) attaching method Possible using an LSGA attaching holder (IHA).
Mounting on the equipment
Insertion (attaching hole diameter 24.5 mm).
Mounting using a clamping knob.
Load up to 3 kg.
Weight Approx. 600 grams
+0.2
0
+0.06
+0.01
