Olympus SZ2-STS - Modules and Nomenclature; Arm for SZX Stand SZ2-STS; Bonder Arm SZ2-STB1

1
32 mm
15.8 mm
MODULES AND NOMENCLATURE
}All of the modules are provided with the electrostatic discharge (ESD) feature. However, the clamping knobs of the SZ2-
STS/STB2/STB3 are not provided with the ESD feature.
Arm for SZX Stand
SZ2-STS
Equipment mounting hole
Bonder Arm
SZ2-STB1
LSGA attaching position
Clamping knob
Focus
adjustment
knob
LSGA attaching position
x 5 positions
Clamping
screw
x 5 positions
Allen wrench
Width across flats 3 mm
Retaining screw
x 3 screws
Equipment mounting shaft
Focus
adjustment
knob
