3
NOMENCLATURE
Universal Condenser
Optical element index plate
mounting position (Page 29)
Aperture iris diaphragm
scale (Page 7)
Aperture iris diaphragm
lever (Page 7)
Optical element index window
Top lens swing-out lever
Top lens (Page 21)
The standard, dry type top lens (U-TLD) can
be exchanged with the oil immersion type
top lens (U-TLO).
Turret
Stage clamping screw*
* For easier viewing of the optical element index window, replace the stage clamping knob with this screw.
(Note) : Used when the U-UCD8 is combined with the IX/IX2
Series or BX51WI microscope. (Page 33)
Number sticker attaching groove
Number index (guideline)
