• Instruction manual (this manual)
• OLYMPUS distributor list
1
2
3
4
5
6
7
8
9
0
a
b
1 Gas outlet valve
2 AUTO CHECK lamp
3 TEST button/CHARGE lamp
4 Dial
5 ZOOM button
• Sets the firing angle within 12 - 42 mm
(24 - 85 mm with the 135 type).
6 Arm mount
7 Arm mount knob
8 POWER button
9 TTL cable connector
0 LIGHT button
• Press to light up the control panel for
about 15 sec.
a MODE button
b Control panel
Silicone grease O-ring remover Flash leash
