Preparation for Use
MOBILE WORKSTATION WM-NP2
44
5. Refer to Figure 4.21 for placement of the endoscope and scope connector in the scope
hanger assembly. To adjust the height of the scope pole, support the vertical pole with one
hand whilst loosening the handwheel with the other hand. Re-position the pole and secure
the handwheel.
• To prevent user or patient cross-contamination, do not hang
contaminated endoscopes on the scope hangers.
• Before attempting to move the workstation outside the procedure room,
ensure that the endoscope and fluid containers are removed.
• Mobile scopes, such as LF-TP/DP/GP, are not compatible with the
scope hangers.
Figure 4.21
