B550 B660 B680
Chap.7 - pag.
O.M.A.C. s.r.l.
Via Giovanni Falcone, 8 42048 Rubiera (RE) - Italy Tel.0522/629371 - 629923 Fax 0522/628980
E-mail:info@omacpompe.com SitoWeb:www.omacpompe.com
26
Rev.4 del 01/2010 O.M.A.C. s.r.l.
POS.
DESCRIPTION Q.TY
B550 B660 B680
200
SEAL STOP PIN
2
2014B200 - -
201
SINGLE MECHANICAL SEAL
2
see par. 7.1.4.6
210
BALANCING RING
2
see par. 7.1.4.5
218
SCREW
12
410A10X20 411A06X20S
220
FLUSHING SEAL BOX
2
2014B144 2014B164
221
O-RING
2
404T4437 404T4625
222
SCREW
12
411A10X40 -
223
SEAL RING UM
2
402V1109510 402U19016015
224
ROTATING RING
2
2004B166 2004B155
225
BUSH O-RING
6
404T4312 404T4475
226
GRANO DI FISSAGGIO ANELLO ROTANTE
6
420A08X06 420A08X12
227
SPINA
4
417A08X15 -
230
BALANCING RING U7K (SINGLE MECH. SEAL)
2
see par. 7.1.4.5
231
BALANCING RING U7K
(DOUBLE MECH. SEAL)
2
see par. 7.1.4.5
232
O-RING
2
404T4437 404T215
233
SCREW
6
- 410A14X30
234
BEARING BOX FOR DOUBLE SEALS
1
- -
235
FLUSHING BOX FOR DOUBLE SEAL
2
2014B160 2014B152
236
COVER
2
2014B162 2014B158
237
SCREW
4
410A10X20 410A10X20
238
O-RING
2
404T4437 404T4562
239
SEAL PROTECTION
2
4034A008 4034A006
240
UM LIP SEAL IN °VITON (F.K.M.)
4
402V857010 402V13011010
240
UM LIP SEAL IN E.P.D.M.
4
402U857010 402U13011010
240
S1 LIP SEAL
2
402Q857010 402Q13011010
240
DOUBLE HN LIP SEAL
4
- -
241
ROTATING BUSH FOR UM / S1 LIP SEAL
2
2004B159 2004B160
241
ROTATING BUSH FOR HN SEAL
2
- -
242
BUSH O-RING FOR UM / S1 LIP SEAL
2
404T168 404T4400
242
BUSH O-RING FOR HN LIP SEAL
2
- -
243
UM / S1 PIN
6
420A06X06 420A08X10
243
HN PIN
6
- -
244
UM SUPPORT
2
2014B054 2014B056
244
S1 SUPPORT
2
2014B064 -
244
HN SUPPORT
2
404T4437 -
245
UM O-RING SUPPORT
2
410A10X25 404T4625
245
HN O-RING SUPPORT
2
410A10X25 -
246
UM SUPPORTSCREW
6
- 410A14X20
246
S1 SUPPORT SCREW
6
- -
246
SCREW FOR HN LIP SEAL FLANGE
6
- -
247
PIN FOR HN LIP SEAL FLANGE
4
417A08X15 -
247
FOR UM LIP SEAL FLANGE
4
- -
280
KIT PACKING GLAND IN P.T.F.E.
1
205P80968 205P11013412
281
STUFFING BOX SEAL SUPPORT
2
2004B164 2004B165
282
ROTATING BUSH O-RING
2
404T168 404T4400
283
SCREW
6
420A06X06 420A08X10
284
STUFFING BOX SEAL SUPPORT
2
2014B074 2014B076
285
FLANGE SUPPORT O-RING
2
404T4437 404T4625
286
SCREW
3
411A10X16 419A14X110
287
PIN
4
417A08X16 -
288
PACKING GLAND ADJUSTER
2
2014B104 2014B106
289
SCREW
2
410A10X25 413A14
