OMAC B430 - Page 107

29
O.M.A.C. s.r.l.
Via Giovanni Falcone, 8 42048 Rubiera (RE) - Italy Tel.0522/629371 - 629923 Fax 0522/628980
E-mail:info@omacpompe.com SitoWeb:www.omacpompe.com
Rev.4 del 01/2010 O.M.A.C. s.r.l.
Chap.7 - pag.
COD. SEAL MATERIAL SEAL MODEL B550 B660 B680
6
CERAMIC / CARBON
O-RING IN E.P.D.M.
KL2A
- -
C5E
4U065C5EBVE -
CERAMIC / CARBON
O-RING IN °VITON
KL2A
- -
C5E
4U065C5EBVV -
CERAMIC / CARBON
O-RING IN P.T.F.E.
KL2A
- -
C5E
4U065C5EBVP -
SILICON CARBIDE / CARBON
O-RING IN E.P.D.M.
KL2A
4U065KL2AZUE 4U100KL2AZUE
SILICON CARBIDE / CARBON
O-RING IN °VITON
KL2A
4U065KL2AZUV 4U100KL2AZUV
SILICON CARBIDE / CARBON
O-RING IN P.T.F.E.
KL2A
4U065KL2AZUP 4U100KL2AZUP
7
CERAMIC / RULON
O-RING IN E.P.D.M.
C5E
4U065C5EYVE -
CERAMIC / RULON
O-RING IN °VITON
C5E
4U065C5EYVV -
CERAMIC / RULON
O-RING IN P.T.F.E.
C5E
4U065C5EYVP -
8
SILICON CARBIDE / SILICON CARBIDE
O-RING IN E.P.D.M.
KL2A
4U065KL2AUUE 4U100KL2AUUE
SILICON CARBIDE / SILICON CARBIDE
O-RING IN °VITON
KL2A
4U065KL2AUUV 4U100KL2AUUV
SILICON CARBIDE / SILICON CARBIDE
O-RING IN P.T.F.E.
KL2A
4U065KL2AUUP 4U100KL2AUUP
9
SILICON CARBIDE / TUNGSTEN CARBIDE
O-RING IN E.P.D.M.
KL2A
4U065KL2AUKE 4U100KL2AUKE
SILICON CARBIDE / TUNGSTEN CARBIDE
O-RING IN °VITON
KL2A
4U065KL2AUKV 4U100KL2AUKV
SILICON CARBIDE / TUNGSTEN CARBIDE
O-RING IN P.T.F.E.
KL2A
4U065KL2AUKP 4U100KL2AUKP
7.1.5 Name and codes of pumping bodies
This naming refers to position n. 40 (pumping body) of the construction exploded view drawings in sections 7.1.1.1, 7.1.2.1, 7.1.3.1, 7.1.4.1 and identifi es
the item code to order as a spare part.
Example: code 23102B07
Code 23102B07 identifi es the fi nished body, with heated chamber, for mechanical seals, for DIN11851 openings, made of AISI 316 L material, for the
size of the LDPU.
The code of the pump bodies is made up as follows:
A B C D E F G G
A CODIFY
2 = FINISHED PART 5 = SEMIFINISHED PART 6 = CAST PART
B FAMIGLIA
3 = FAMILY MEMBERSHIP
C VERSION
0 = STANDARD 1 = HEATED PUMP BODY 2 = ASEPTIC 3 = HEATED ASEPTIC
4 = HIGH PRESSURE
5 = HIGH PRESSURE +
HEATED PUMP BODY
6 = ENLARGED
INLET PORT
7 = ENLARGED
INLET PORT +
HEATED PUMP BODY
D
HOUSING TYPE
SEALS
0 = MECHANICAL AND LIP SEAL 1 = PACKING GLAND SEAL 9 = SPECIAL
E CONNECTIONS
0 = THREAD GAS-BSP
1 = FLANGE PN 16
UNI2278
2 = DIN11851 3 = SMS 4 = RJT
5 = IDF-ISS 6 = TRI-CLAMP 7 = GAS 8 = ENOLOGIC 9 = SPECIAL
F MATERIAL
B H I J R
G-G Numerical order in relation to the size
2 3 1 0 2 B 0 7
A B C D E F G G
