OMAC B430 - Page 97

B2 B3 B4 B470 B490
O.M.A.C. s.r.l.
Via Giovanni Falcone, 8 42048 Rubiera (RE) - Italy Tel.0522/629371 - 629923 Fax 0522/628980
E-mail:info@omacpompe.com SitoWeb:www.omacpompe.com
Chap.7 - pag.
19
Rev.4 del 01/2010 O.M.A.C. s.r.l.
7.1.3.6 B215 B220 B325 B330 B390 B430 B470 B490: Single and double mechanical seals codes
COD. SEAL MATERIAL SEAL MODEL B215 B220 B325 B330 B390 B430 B440 B470 B490
3
Q3
S.S. AISI 316 L / CARBON
O-RING IN EPDM
U7K
4U035U7KXZ7 4U050U7KXZ7 4U065U7KXZ7 4U080U7KXZ7
KL2A
4U035KL2AXZY 4U050KL2AXZY 4U065KL2AXZY 4U080KL2AXZY
C5E
4U035C5EBGE 4U050C5EBGE 4U065C5EBGE 4U080C5EBGE
S.S. AISI 316 L / CARBON
O-RING IN °VITON
U7K
4U035U7KXZY 4U050U7KXZY 4U065U7KXZY 4U080U7KXZY
KL2A
4U035KL2AZYV 4U050KL2AZYV 4U065KL2AZYV 4U080KL2AZYV
C5E
4U035C5EBGV 4U050C5EBGV 4U065C5EBGV 4U080C5EBGV
S.S. AISI 316 L / CARBON
O-RING IN P.T.F.E.
U7K
4U035U7KXZP 4U050U7KXZP 4U065U7KXZP 4U080U7KXZP
KL2A
4U035KL2AZYP 4U050KL2AZYP 4U065KL2AZYP 4U080KL2AZYP
C5E
4U035C5EBGP 4U050C5EBGP 4U065C5EBGP 4U080C5EBGP
4
TUNGSTEN CARBIDE / CARBON
O-RING IN E.P.D.M.
U7K
4U035U7K3Z7 4U050U7K3Z7 4U065U7K3Z7 4U080U7K3Z7
KL2A
4U035KL2AKZE 4U050KL2AKZE 4U065KL2AKZE 4U080KL2AKZE
C5E
4U035C5EBUE 4U050C5EBUE 4U065C5EBUE -
TUNGSTEN CARBIDE / CARBON
O-RING IN °VITON
U7K
4U035U7K3ZY 4U050U7K3ZY 4U065U7K3ZY 4U080U7K3ZY
KL2A
4U035KL2AKZV 4U050KL2AKZV 4U065KL2AKZV 4U080KL2AKZV
C5E
4U035C5EBUV 4U050C5EBUV 4U065C5EBUV -
TUNGSTEN CARBIDE / CARBON
O-RING IN P.T.F.E.
U7K
4U035U7K3ZP 4U050U7K3ZP 4U065U7K3ZP 4U080U7K3ZP
KL2A
4U035KL2AKZP 4U050KL2AKZP 4U065KL2AKZP 4U080KL2AKZP
C5E
4U035C5EBUP 4U050C5EBUP 4U065C5EBUP -
5
Q5
TUNGSTEN CARBIDE / TUNGSTEN CARBIDE
O-RING IN E.P.D.M.
U7K
4U035U7K337 4U050U7K337 4U065U7K337 4U080U7K337
KL2A
4U035KL2AKKE 4U050KL2AKKE 4U065KL2AKKE 4U080KL2AKKE
C5E
4U035C5EUUE 4U050C5EUUE 4U065C5EUUE -
TUNGSTEN CARBIDE / TUNGSTEN CARBIDE
O-RING IN °VITON
U7K
4U035U7K33Y 4U050U7K33Y 4U065U7K33Y 4U080U7K33Y
KL2A
4U035KL2AKKV 4U050KL2AKKV 4U065KL2AKKV 4U080KL2AKKV
C5E
4U035C5EUUV 4U050C5EUUV 4U065C5EUUV -
TUNGSTEN CARBIDE / TUNGSTEN CARBIDE
O-RING IN P.T.F.E.
U7K
4U035U7K33P 4U050U7K33P 4U065U7K33P 4U080U7K33P
KL2A
4U035KL2AKKP 4U050KL2AKKP 4U065KL2AKKP 4U080KL2AKKP
C5E
4U035C5EUUP 4U050C5EUUP 4U065C5EUUP -
6
CERAMIC / CARBON
O-RING IN E.P.D.M.
KL2A
4U035KL2AZCE 4U050KL2AZCE - -
C5E
4U035C5EBVE 4U050C5EBVE 4U065C5EBVE 4U080C5EBVE
CERAMIC
CARBON
O-RING IN °VITON
KL2A
4U035KL2AZCV 4U050KL2AZCV - -
C5E
4U035C5EBVV 4U050C5EBVV 4U065C5EBVV 4U080C5EBVV
CERAMICA
CARBON
O-RING IN P.T.F.E.
KL2A
4U035KL2AZCP 4U050KL2AZCP - -
C5E
4U035C5EBVP 4U050C5EBVP 4U065C5EBVP 4U080C5EBVP
SILICON CARBIDE / CARBON
O-RING IN E.P.D.M.
KL2A
- - 4U065KL2AZUE 4U080KL2AZUE
SILICON CARBIDE / CARBON
O-RING IN °VITON
KL2A
- - 4U065KL2AZUV 4U080KL2AZUV
SILICON CARBIDE / CARBON
O-RING IN P.T.F.E.
KL2A
- - 4U065KL2AZUP 4U080KL2AZUP
7
CERAMIC / RULON
O-RING IN E.P.D.M.
C5E
4U035C5EYVE 4U050C5EYVE 4U065C5EYVE -
CERAMIC / RULON
O-RING IN °VITON
C5E
4U035C5EYVV 4U050C5EYVV 4U065C5EYVV -
CERAMIC / RULON
O-RING IN P.T.F.E.
C5E
4U035C5EYVP 4U050C5EYVP 4U065C5EYVP -
8
SILICON CARBIDE / SILICON CARBIDE
O-RING IN E.P.D.M.
KL2A
4U035KL2AUUE 4U050KL2AUUE 4U065KL2AUUE 4U080KL2AUUE
SILICON CARBIDE / SILICON CARBIDE
O-RING IN °VITON
KL2A
4U035KL2AUUV 4U050KL2AUUV 4U065KL2AUUV 4U080KL2AUUV
SILICON CARBIDE / SILICON CARBIDE
O-RING IN P.T.F.E.
KL2A
4U035KL2AUUP 4U050KL2AUUP 4U065KL2AUUP 4U080KL2AUUP
9
SILICON CARBIDE / TUNGSTEN CARBIDE
O-RING IN E.P.D.M.
KL2A
4U035KL2AUKE 4U050KL2AUKE 4U065KL2AUKE 4U080KL2AUKE
SILICON CARBIDE / TUNGSTEN CARBIDE
O-RING IN °VITON
KL2A
4U035KL2AUKV 4U050KL2AUKV 4U065KL2AUKV 4U080KL2AUKV
SILICON CARBIDE / TUNGSTEN CARBIDE
O-RING IN P.T.F.E.
KL2A
4U035KL2AUKP 4U050KL2AUKP 4U065KL2AUKP 4U080KL2AUKP
